SPECIFICATIONS

Battery Properties: Rechargeable Battery

Item ID: WM2286005

Operating Voltage: ≤36V

Origin: Guangdong,China

Power Mode: Battery Powered/USB Dual Use

Rechargeable Battery: Lithium Battery-Other Series

Walkie-talkie Frequency Band (MHZ): 150-174&450-480MHz

l
FrequencyRange
150-174&450-480MHz
Channel No.
3000
Antenna impedance
50Ω
Operating Voltage
7.4 V DC
Operating Temperature
-30°C~+60°C
Dimension(W x H x D)
131x61x36mm
Battery
2200mAh Li-ion
Transmitter
Output power
≤5W(H) ≤1W(L)
Vocoder type
TDMA
Frequency Stability
± 1.0 PPM
Adjacent channel power
≤-60dB
Spurious Radiation
Antenna:9KHz-1GHz,≤ -36dBm
1GHz-12.75GHz,≤-30dBm
Hum and noise
-40dB *12.5KHz

4 FSK Digital Mode
12.5KHz(data only):7k60FXD
12.5KHz(data+voice)7k60FXE
Receiver
Digital sensitivity
0.25uV (BER 5%)
Audio power
1W
Autio response
=1dB-3dB
Adjacent Channel Selectivity
≤-60dB *12.5KHz
